Factory Price Mini ELM327 V1.5 Bluetooth Interface OBD2 ELM327 Car Code Reader ELM 327 Car Diagnostic Scanner
ELM327 does not support all brand cars, if you are not sure it supports your cars, please don’t purchase !
ELM327 in this link DO NOT support IOS system !!!
It only works with car (does not support truck).
It only works with Android 4.0-Android 4.4 version. or 5.0
Please connect the item to your phone through bluetooth OBD II option.
ELM327 can do most of the OBDII vehicles, but it can not do all models. If any question, pls kindly contact with us.
If the driver CD was broken, please contact us and we will provide a download link or send the software to you through Email, Do not open dispute, Thanks!!
If you are not sure whether this mini elm327 Bluetooth can works on your car, please do not place the order.
If you can not connect with bluetooth, please check if you choose the bluetooth connect way in software setting. or contact us directly, do not open dispute!
ELM-327 Bluetooth Highlights:
The newly developed wireless scan tool.
It supports almost OBD-II protocols.
Bluetooth connection, no Batteries, Cables, or Switches.
Wireless (Bluetooth) 5~10 meter
Retrieve Fault Codes (DTCs) and clear Check Engine lights.
Can also be used with a PC with a Bluetooth Card.
Read diagnostic trouble codes, both generic and manufacturer-specific , and display their meaning (over 3000 generic code definitions in the database).
Clear trouble codes and turn off the MIL (“Check Engine” light)
Set the maximum number of responses to obtain
Remove spaces from ECU responses (to speed data transmission)
Store a unique identifier in EEPROM
Set the CAN mask and filter with one command
Easily switch between variable and fixed CAN message lengths
Send CAN remote frames (RTRs)
Display current sensor data, including:
Calculated Load Value
Fuel System Status
Short Term Fuel Trim
Long Term Fuel Trim
Intake Manifold Pressure
Intake Air Temperature
Air Flow Rate
Absolute Throttle Position
Oxygen sensor voltages/associated short term fuel trims
Fuel System status
1.SAE J1850 PWM(41.6Kbaud)
2.SAE J1850 VPW(10.4Kbaud)
3.ISO9141-2(5 baud init,10.4Kbaud)
4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5.ISO14230-4 KWP(fast init,10.4 Kbaud)
6.ISO15765-4 CAN(11bit ID,500 Kbaud)
7.ISO15765-4 CAN(29bit ID,500 Kbaud)
8.ISO15765-4 CAN(11bit ID,250 Kbaud)
9.ISO15765-4 CAN(29bit ID,250 Kbaud)
A.SAE J1939 CAN(29bit ID,250*Kbaud)
B.USER1 CAN(11*bit ID,125*Kbaud)
C.USER2 CAN(11*bit ID,50*kbaud)
*default settings(user adjustable)
Works on all OBD2 Vehicles (1996 onwards in USA) and EOBD vehicles ( Petrol cars from 2001 and diesel cars from 2003/2004 in Europe)
For your information:
For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant.
for Al-fa R-omeo/ for Au-di/ for Bent-ley/ for B*M*W/ for C-adillac/ for C-hevrolet/ for Chry-sler/ for C-itroen/ for Dae-woo/ for F-iat/ for F-ord/ for G-M/ for Hond*a/ for H-yundai/ for Isuzu/ for J-eep/ for K-ia/ for L-and-over/ for L-exus/ for M-azda/ for Mercury/ for Mini/for N-issan/for M-itsubishi/for Opel/ for P-eugeot/ for Renault/ for Rover/ for Saab/ for Seat/for Sk-oda/ for T-oyota/ for Vauxhall/ for V-olvo/ for V-W
This hardware can match many other software still!But most of them are not free!
Works for Windows98/ME/2000/XP/Vista & 7 !
This tool does not match abs and airbag system!
Bluetooth pair code: 1234
Main Control Chip: PIC18F2480
1 X Mini ELM327 Bluetooth Diagnostic Interface
Type 1: Blue mini ELM327 V2.1 Software
(comes with install guide, no CD, no packing box )
Type 2: Black mini ELM327 V1.5 Software
(Comes with CD, NO Packing BOX)
Type 3: White mini ELM327 V1.5 Software
(comes with CD, NO Packing Box)
Type 4: Blue MINI ELM327 V1.5 with Packing BOX
(Comes with packing box, NO CD, download software from QR-Code, or from link)
Q: What’s the version of this unit?
A: It’s V2.1 version
Q: What’s the Password of the Bluetooth?
A: “1234” .
Q: My phone can connect with the unit, but it can’t find my car?
A: 1. please check if you choose the “OBD II” adapter of ” adapter choice” in setting software.
2. check if your android system version is V4.0 – 4.4 or V5.0.
3. check the protocol of this car if it can be supported, and try with more new cars.
Q: Does it can support all car and diesel models?
A: No, it can just support most standard OBD II car models, if you car is before 2005,it maybe can’t support your car.and the J1850 protocols car models can’t be supported. Dieser car models can’t be supported.
Q: Which android system phone can compatible? Does it can compatible with Iphone?
A: Please kindly use Android V 4.0- 4.4 or V5.0. It can’t support IOS system.
Q: Why my computer can’t connect with this Bluetooth?
A: This unit is with V2.0 version Bluetooth, check your computer if it’s V2.0 version, or please use V2.0 bluetooth adapter.
Q: Why my phone can’t connect with the Bluetooth?
A: Please kindly check if you choose the bluetooth connect way in software setting.
